frame MISSION CF4 II
material: carbon
700x40C max.WHS
100x12/142x12mm axle standard
BSA bottom bracket
frame size XXS, XS, S, M, L, XL
color WILD HONEY (BLACK
)
fork MERIDA MISSION CF4 II
Tapered
material: carbon
700x45C max. wheelsize
brakes Sram Rival AXS XPLR
rotors Sram Paceline RT-PLN-A2
160 mm
brake lever Sram Rival AXS XPLR
headset Acros ICR MERIDA external neck w/diecast splitring
handlebar MERIDA EXPERT GR II
material: aluminium
380mm (XXS-XS-S) , 400mm (M-L) , 420mm (XL)
handlebar stem MERIDA TEAM CC III
material: aluminium
31.8mm diameter
-6°° stem angle
90 mm-XXS/XS/S, 100 mm-M, 110 mm-L/XL
grip MERIDA ROAD EXPERT
derailleur (r) Sram Rival XPLR
AXS wireless T-Type
shifters Sram Rival AXS
seat post MERIDA EXPERT SL
27.2mm diameter
0mm setback
Carbon
seat clamp MERIDA EXPERT
saddle MERIDA COMP SL
chain Sram Rival
Flattop
crank Sram Rival XPLR
42 teeth
MAT Aluminium
165mm-XXS/XS, 170mm S/M, 172,5mm L/XL
freewheel Sram Rival XPLR
10-46 teeth
13 speed
bottom bracket Sram DUB BSA Road Wide
68mm
wheelset DT Swiss G 1800 spline
CL
100x12mm width front hub
142x12mm width rear hub
24mm inner width
25mm height
Centerlock
material: aluminium
tyre front Continental Terra Speed ProTection 40mm
40-622
TLR
foldable skin SL
tyre rear Continental Terra Speed ProTection 40mm
40-622
TLR
foldable skin SL
axles MERIDA EXPERT TR
L=165,5mm M12x1,0 *including removable lever
6/4mm allen key
spokes Black stainless
approx. weight 9.1 kg
weighed at frame size M
max. weight 120 kg
